Tempnote® V1.0

GET A PRICE/QUOTE ASK A QUESTION RECEIVE DOCUMENTATION

The “do-it-all” DATA LOGGER you can trust

Special Features
  • -30°C to +70°C
  • 18 Months service life
  • Automatic PDF Reports
  • User programmable
  • Very small and light
  • Waterproof and food-safe
  • Validation Certificate Included

Description

Monitoring your cold chain have become very easy with most economical, super compact single use datalogger Tempnote® V1.0.

Tempnote® data loggers are extremely engineered for seamless performance to monitor door to door cold chain shipments. Tempnote® data loggers are pre-configured and ready to use device. Moreover, it also can be set to user specific requirement like 2C-8C, 15C-25C, -25C to -15C or any customize temperature range, sampling interval and start delay by our Tempnote® Analyzer Software. Tempnote® dataloggers auto generates PDF report without requiring additional cable/hardware or software. PDF report contains graphical as well as tabular data interpretation. Its first page contains summary of entire journey, start & stop date/time, Max/Min/Avg./MKT temperature, and excursion details.

Technical Features

  • 18 Month shelf life
  • Automatic PDF report
  • Up to 60 days recording time
  • Re-programmable by user
  • Calibration Certificate
  • Records every temperature fluctuations
  • Compact & Slim design
  • Most economical cold chain monitoring device for transportation
  • Protective cover: waterproof and food-safe
  • No additional software required to generate report
  • Reports in Graphical and Tabular manner
  • Secured tamper-proof PDF report file
  • LED light indication for current temperature status
  • Validation Certificate Included at no extra cost
Tempnote® V1.0 offers best in its class performance for cold chain monitoring for temperature sensitive shipments. Tempnote® V1.0 is factory configured with default settings. However, customer can change default setting to their specific requirement and repack it in the provided double locks waterproof plastic sleeve. Following parameters can be set by our Tempnote® Analyzer software.
  • Running time of up to 60 days
  • Start Delays, Maximum, Minimum Temperature Range
  • Sampling Interval time
  • Time zone

Tempnote® V1.0
Technical Data

Additional information

Brand

Tempnote®

Model

V1.0

Country

UK, USA

Type

Single Use

Measures

Temperature

Temperature Range

-30°C to +70°C

Temperature Accuracy

0.5°C

Temperature Resolutions

0.1°C

Sensor

Internal

Sampling Memory

10,000 Readings

Configuration

User Configurable

PC connectivity

inBuilt USB

Report Format

PDF

Auto Generates PDF report

Yes

Software

Free to download from website

Report Type

Graphical & Tabular

LED Indication

Yes

LCD Display

No

Certifications

EN12830 European Standards CE, RoHS

Validation Certificate

Six poins NIST Traceable validaion certificate included, Yes

Unique Serial Number

Yes

Shelf Life

18 Months
